40a 12/48v MPPT Cee Power Charge Controllers

The CEE POWER 40A/12V/48V MPPT Controller is a robust and efficient solar charge controller that utilizes advanced Maximum Power Point Tracking (MPPT) technology to optimize the energy output from your solar panels. This controller is compatible with both 12V and 48V systems, providing versatility for a wide range of solar applications. With a 40A charging capacity, it is designed for medium to large solar setups, ensuring a reliable and fast charging solution for your batteries. The controller is equipped with essential safety protections to prevent overcharging, overheating, and other system failures, ensuring long-term performance and reliability.

Key Features:

MPPT Technology: Maximizes energy conversion efficiency to ensure optimal battery charging.

Dual Voltage Compatibility: Supports both 12V and 48V systems for flexible application.

40A Charging Capacity: Suitable for larger solar systems, handling high current loads efficiently.

Automatic Voltage Detection: Automatically detects and adjusts for the system's voltage.

Overcharge Protection: Stops charging automatically when the battery reaches full charge to avoid overcharging.

Overload Protection: Provides protection against excessive power consumption.

Reverse Polarity Protection: Safeguards the system from damage due to incorrect wiring connections.

Short Circuit Protection: Automatically shuts down to protect against short circuit conditions.

Temperature Compensation: Adjusts charging parameters based on ambient temperature for optimal performance.

Clear LCD Display: Displays real-time system data, including charging status and battery voltage.

Efficient Cooling System: Designed with excellent heat dissipation for prolonged system life.

Low Standby Power Consumption: Minimizes energy consumption during idle times for better energy efficiency.

Specifications:

Input Voltage Range: 18V - 60V (for 12V system) / 36V - 72V (for 48V system)

Rated Charge Current: 40A

Nominal Battery Voltage: 12V/48V (Auto-detection)

MPPT Tracking Efficiency: ≥ 99%

Conversion Efficiency: ≥ 98%

Maximum PV Input Power: 480W for 12V system / 1920W for 48V system

Operating Temperature: -20°C to 50°C

Storage Temperature: -40°C to 70°C

Display Type: LCD screen for system status and data readout

Protection Features: Overcharge, over-discharge, short circuit, reverse polarity, and over-voltage protections

Material: Durable aluminum casing for enhanced heat dissipation and longevity

Dimensions: 250mm x 210mm x 90mm

Weight: 1.5kg

Warranty: 2 years
