11KW FIREMAN TRANSFORMERLESS INVERTER

The Firman 11kW Hybrid On-Off Inverter (FH11K0110) is a high-precision power management system designed for heavy-duty residential and commercial use. It functions as a "hybrid" unit, meaning it intelligently switches between solar, battery, and grid power to ensure 24/7 electricity.

Core Functionality & Design

Dual Architecture: Available in two main versions to suit different needs:

Transformer-Based (Low Frequency): Uses a heavy iron-core transformer, providing galvanic isolation for superior safety and the ability to handle high "surge" currents from inductive loads like pumping machines and large ACs.

Transformerless (High Frequency): Uses advanced electronics to be more energy-efficient (up to 99%) and significantly lighter (~19.3kg), making it ideal for modern homes with lithium setups.

Smart Energy Management: Features a configurable priority system (via touch screen) that lets you decide whether to use solar, battery, or the grid first.

Parallel Capability: The system can be expanded by connecting up to 6 units in parallel for massive power requirements.

Technical Specifications

Power Capacity: 11,000 Watts rated output with a 1.0 Power Factor, meaning it delivers its full stated wattage.

Solar Input: Equipped with dual MPPT controllers supporting a maximum PV array of 11,000W (2 x 5,500W) and a high input voltage range of 120V to 500V.

Battery System: Operates on a 48V DC nominal voltage; compatible with both Lead-Acid and Lithium-ion (LiFePO4) batteries with a dedicated BMS communication port (RS485/CAN).

Operating Noise: Extremely quiet operation at less than 45dB, making it suitable for indoor installation.

Operational Features

Monitoring: Built-in Wi-Fi data logger (optional) and an intuitive LCD/LED display for real-time tracking of battery status, load levels, and fault records.

Protection: Includes an IP20-rated enclosure and comprehensive safeguards against over-voltage, short circuits, and over-temperature.

WiFi Control: Features integrated WiFi functionality for remote monitoring via smartphone apps.
